Zipper Pouch Packing Machine

Zipper Pouch Packing Machine Specification

Filling Range
10 g 1 kg

Application
Zipper pouch filling and sealing for food, pharmaceuticals, and other granules/powders

Usage
Used for automatic filling and packing of zipper pouches

Noise Level
Low (<70 dB)

Power Supply
Single Phase/Three Phase

Features
Touch Screen Interface, Product Counting, Batch Coding Optional

Type
Zipper Pouch Packing Machine

Material
Stainless Steel

Feature
High Speed, Accurate Filling, Easy Operation, Low Maintenance

Auxiliary Packaging Machine Type
Automatic Pouch Feeder

Capacity
30-60 pouches/min

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control Panel

Drive Type
Electric

Power
2.5 kW

Voltage
220-240 V AC

Weight (kg)
approx. 750 kg

Dimension (L*W*H)
2200 mm x 1300 mm x 1600 mm

Color
Silver/Grey

Sealing Type
Heat Seal

Max Roll Diameter
400 mm

Packing Material
PE, PET/PE, BOPP

Hopper Capacity
40 liters

Compressed Air Requirement
0.6 MPa, 0.3 m/min

Bag Width Range
80-260 mm

Packaging Accuracy
+/ 1.5%

Film Thickness
0.04-0.12 mm

Bag Length Range
100-350 mm

Zipper Pouch Packing Machine Trade Information

Minimum Order Quantity
2 Pieces

Supply Ability
30 Pieces Per Month

Delivery Time
2-3 Days

About Zipper Pouch Packing Machine

We take immense pleasure to introduce ourselves as a trusted manufacturer and supplier of Zipper Pouch Packing Machine. It is used for zipper pouch packaging of shampoo, snack, hair oil, sauces, detergent and other products. At our sound production unit, we manufacture this machine using high quality materials and components. This machine is equipped with a programmable logic controller for controlling each and every operation with utmost safety. Also, this Zipper Machine is properly enclosed to prevent cross contamination of packing contents. We offer this machine at cost effective prices to clients.

Zipper Pouch Packing Machine Features:

Easy to operate
High working efficiency
Perfect finish
High operational fluency
User friendly design
Low energy consumption

Advanced Control for Enhanced Efficiency

Equipped with a modern PLC control panel and touch screen interface, this zipper pouch packing machine provides seamless operation and monitoring. The computerized system ensures precise adjustments, product counting, and optional batch coding, streamlining the packaging workflow for high-volume production.

Versatile and Accurate Packaging Solutions

Designed to accommodate a variety of packaging materials such as PE, PET/PE, and BOPP films with a thickness of 0.04-0.12 mm, this machine delivers reliable sealing and filling for food, pharmaceutical, and other granule or powder products. The adjustable hopper and wide bag size range offer flexibility for different production requirements.

Durable Build with User-Centric Features

Manufactured from corrosion-resistant stainless steel, this machine combines durability with an easy-to-clean surface. Key attributes include high-speed operation, low maintenance, and minimal noise levels, making it a dependable choice for continuous use in demanding manufacturing environments.

FAQ's of Zipper Pouch Packing Machine:

Q: How does the Zipper Pouch Packing Machine operate?

A: The machine uses a PLC control panel and touch screen interface to automate the filling and sealing of zipper pouches. Operators set parameters such as pouch size, filling weight, and speed. The automatic pouch feeder supplies empty pouches, which are then filled and heat-sealed with high accuracy and speed.

Q: What types of products can be packed with this machine?

A: It is designed to handle granules and powders, including food items (like snacks and spices), pharmaceutical powders, and similar products. The adjustable filling range (10 g to 1 kg) supports a broad spectrum of applications across multiple industries.

Q: When is this machine most beneficial for a packaging operation?

A: This packing machine is ideal for manufacturers or distributors looking for high-speed, accurate, and low-maintenance pouch packaging. It is especially useful in processes requiring frequent changeovers between pouch sizes or different products, ensuring efficient and streamlined production.

Q: Where can this machine be installed and used?

A: The Zipper Pouch Packing Machine is suitable for use in manufacturing facilities involved in food processing, pharmaceuticals, or any sector requiring clean and efficient pouch filling and sealing. Its compact dimensions facilitate integration into existing production lines.

Q: What is the process for switching between different pouch sizes or products?

A: Operators use the touch screen to select the desired bag width, length, and filling quantity. The machine's adjustable settings and automatic pouch feeder enable quick changeovers between sizes and types, reducing downtime between production batches.

Q: What are the primary benefits of using this packing machine?

A: Key advantages include high-speed packing (30-60 pouches per minute), precise filling (1.5%), low noise operation, minimal maintenance requirements, and enhanced usability via the user-friendly control system. Additional features like product counting and optional batch coding further increase operational efficiency.

Q: How does the machine maintain filling and sealing accuracy?

A: Equipped with advanced sensors and PLC-controlled mechanisms, the machine precisely measures and dispenses each product portion. The heat sealing system ensures secure closure, while computerized monitoring helps maintain accuracy throughout the packaging process.
